Discovery-2TM Spirometer

Despite its compact size, Discovery-2 is complete and can be used to test patients and print reports virtually anywhere.



Adults and children find the ergonomical
Discovery-2 sensor easy to handle.


Tests

- Forced Vital Capacity (F-V Loops)
- Slow Vital Capacity
- Maximum Voluntary Ventilation
- Respiratory Pattern
- Pre/Post Medication comparisons
- Broncho-challenge testing
- Trending

Measured Parameters

FVC, FEV1, PEF, FEV1/FVC, FEV6, FEV6/FVC, FEV1/FEV6, FEF25-75, FET100%, VEXT, FIVC, PIF, VC (SVC), IVC, MVV, FEV1/VC%, ERV, IRV, VE, Rf, ti, te, ti/t.tot, Vt/Ti, IC, MEF75, MEF50, MEF25, Best FVC, Best FEV1, Lung age.

Predicted Values

NHANESIII, ITS, Knudson 83, Knudson 76, Morris, Bass, ERS 93 (ECCS 83), ECCS 71, Pereira, Thai 2000, LAM, Multicentrico, Pneumobil, Gutierrez.

Discovery-2 Package

Item # Description
D235000



Discovery 2 spirometer
Turbine flowmeter
AC/DC Power Adapter (110-240)
USB communication cable to PC
Mouthpieces (20 adult/20 peds)
Bacterial filter starter kit
Noseclips
Paper
Carrying case
Discovery-2 Software for Windows
Warranty card

Optional Accessories

Item # Description
39250 3 liter calibration syringe
39NA050 Spirometry filters (50/box)
39NA100 Spirometry filters (100/box)
39NA250 Spirometry filters (250/case)
35090 Pediatric mouthpieces (100)
35075 One-way mouthpieces

Standard Features

- Large color display
- Time/volume & Flow/volume graphs in real time
- Fast and complete internal printer
- Alpha-numeric keyboard
- Connection to standard external printers
- Memory
- Optional Oximetry
- Optional Airway Resistance
- Available in English, Spanish, French, and many other languages

PC Software

Futuremed's software for Windows can be used in two unique ways to increase to Discovery-2's value :

-  Patient files can be stored from Discovery-2 to the PC (or from the PC back to the spirometer).

-  The same software can be used to perform tests from Discovery directly onto the PC.

Sensor

Bidirectional digital turbine. Cold-sterilizable. The compact handset is lightweight and easy for adults and children to handle. Used with your choice of mouthpieces or bacterial filters.



Range (volume): 12 liters
Range (flow): 0.03 - 20 l/s
Accuracy: 2%
Flow resistance: <.70 cm H2O/l/s @ 12 l/s

Calibration

Automatic, using 3L syringe per ATS recommendations

Hardware Features

Power: AC/DC with rechargeable battery
Size: ~ 8"x 9"x 3"
19.0 x x 23.8 x 7.6 cm
Weight: 2.6 lbs, 1.2 Kg
Op. Temp.: 0-50 C










Discovery and Discovery-2 are registered trademarks of Futuremed America Inc.


A Discovery slideshow is available at slideshows.
For brochures/sales sheets, please visit brochures.
